AYRLITE® 2054 is principally developed for high-performance marine vessel interior applications

AYRLITE® 2054 is a fully certified aluminium honeycomb panel with decorative laminate faces reinforced with aluminium sheet.

Strain-hardened hexagonal cell aluminium honeycomb has optimum mechanical properties and is able to carry shear loads at much lower weight than foam or other core types.

Advanced adhesive technology has enabled AYRLITE® 2054 to achieve excellent fire performance.

AYRLITE® 2054 has been principally developed for high-performance marine vessel interior applications.

  • Properties
  • Application
  • Colours
  • Processing
  • Accreditations
Properties

Properties

Panels are produced with the same decorative laminate on both faces, or with a backing/lining laminate on the reverse face. Decorative faces are reinforced with Aluminium sheet. A broad range of reinforcement sheet thicknesses are available, including 0.3mm, 0.5mm, 0.8mm and 1.0mm. 0.5mm is the standard reinforcement thickness. Aluminium reinforcement sheets can be selected with different thicknesses on different faces: for example, 0.8mm for front face, 0.3mm for back face Aluminium reinforcement sheets are 5000-series alloy for maximum strength and anti-corrosion performance. Aluminium honeycomb cell size is 6.35mm.

Metric
Imperial

PHYSICAL AND MECHANICAL PERFORMANCE

Thickness Weight Long Beam Flatwise Tensile Flatwise Compression
(mm)
(kg/m2)
Max Load
(Newtons)
Deflection
at Max Load
(mm)
(MPa)
(MPa)
10 4.7 1379 21 1.2 2.6
20 5.3 2697 9 1.2 2.6
30 5.8 3695 7 1.2 2.6
Typical room temperature properties for 0.5mm aluminium faced panels. Mechanical test procedures to AMS-STD-401.

AVAILABILITY

Standard Dimensions
2400mm x 1200mm
Panel Thickness
Made to order, minimum thickness 6mm

PHYSICAL AND MECHANICAL PERFORMANCE

Thickness Weight Long Beam Flatwise Tensile Flatwise Compression
(inches)
(lb/ft2)
Max Load
(lbf)
Deflection
at Max Load
(inches)
(psi)
(psi)
0.4 0.995 214 0.78 145 325
0.8 1.100 421 0.37 145 325
1.2 1.222 632 0.26 145 325
Typical room temperature properties for 0.5mm aluminium faced panels. Mechanical test procedures to AMS-STD-401.

AVAILABILITY

Standard Dimensions
96″ x 48″
Panel Thickness
Made to order, minimum thickness ¼”
Application

Application

Colours

Colours

Download Unleash your imagination Colour Chart

Unleash your imagination

Snow Flake
ACL101

Ivory
ACL113

Silver Lightning
ACL104

Odyssey
ACL106

Night Flight
ACL107

Platinum
ACL303

Crema Limestone
ACL204

Anthracite Granit
ACL205

Light Atelier
ACL206

Maple
ACL220

Bavaria Beech
ACL221

Cherry
ACL222

Amber Urban Oak
ACL223

Walnut
ACL224

Carbon Marine Wood
ACL225

Colours may vary by individual computer monitor from the actual final laminate product. We advise that the final selection is made from an actual sample.

Request a sample
